February 2012 29 – 531
29.4 Exchanging the MC 6222
Preparing the
machine tool
If still possible:
8 Move the machine to home position (axes, tool changer, tilting head, etc.)
Ask the machine operator!
8 Press EMERGENCY STOP.
Backup of
non-volatile PLC
markers and words
8 Back up the condition of non-volatile PLC markers and words from the RAM to the data medium.
--> See ”Non-volatile PLC markers and words” on page 11 – 134.
Removing the
defective MC 6222
8 Switch off the machine, take precautions against resetting, ensure that the equipment is free of
potential.
8 Open the console.
8 Label all lines and cables and disconnect them from the MC.
8 Screw off the ground lead.
8 Dismount the MC from the console.
8 Remove the SSDR. --> See ”Exchanging the SSDR” on page 29 – 537.
8 Remove the SIK (slot X125 on side).
Mounting the
new MC 6222
8 Insert the SSDR into the new MC 6222 and fix it.
--> See ”Exchanging the SSDR” on page 29 – 537.
8 Insert the SIK into the new MC 6222.
8 Mount the MC 6222 in the console.
8 Screw on the ground lead.
8 If required, remove the red protective caps from the MC connectors.
8 Reconnect and attach all lines and cables.
8 Close the console.
8 Switch on the power switch of the machine.
Observe the ESD precautions. --> See ”Important information” on page 29 – 515!
The SIK (System Identification Key) remains with the machine.
It must be inserted into the new or replacement MC; i.e. all enabled options are still available.
Only defective SIKs are exchanged.
If options were enabled on the defective SIK, you will receive the code numbers to enable these
on your new SIK after giving us the number of your defective SIK.
The SIK number is displayed on the screen after you have entered the SIK code number. The
SIK number is also printed on the ID label applied onto the board of the SIK.
The defective SIK must be returned!
Do not forget the grounding screw! Do not confuse any of the connectors!
