HEIDENHAIN iTNC 530 HSCI Service Manual

20 – 326 HEIDENHAIN Service Manual iTNC 530 HSCI
20.6 Corrective action
 Repair the trip dog.
 Replace the encoder. See ”Encoder interface” on page 19 – 277.
 Readjust the displaced magnet or replace the damaged magnet. Do not forget the spacer plates
(filler pieces)!
 Readjust the displaced ref. mark selector plate.
Use a special slider for this purpose. --> Ask a HEIDENHAIN service agency!
 Have the removed or damaged enamel repainted. --> Ask a HEIDENHAIN service agency!
 Adjust the trip dog to the reference pulse of the motor encoder. --> See ”Readjusting the trip dog
for reference end position” on page 19 – 311.
20.7 Deselecting axes referencing
For axis examinations it is possible to deselect referencing in MP1340.x.
8 Enter the value 0 (= no evaluation of the reference mark) for the axis concerned or for all axes.
DANGER
Non-referenced axes have no relation to the machine datum. Software limit switches may be at a
wrong position.
Traversing these axes bears the risk of a crash!
Note
MP1340.x contains the sequence in which the reference marks are traversed.
This means, if the sequence is ...
 MP1340.0 : 3
 MP1340.1 : 2
 MP1340.2 : 1
... first the 3rd axis is referenced (e.g., Z axis), then the 2nd axis (e.g., Y axis) and subsequently
the 1st axis (e.g., X axis).
If you now want to deselect the X axis, you have to enter 0 in MP1340.2.
Normally however, the reference run is deselected for all axes.
