31 – 580 HEIDENHAIN Service Manual iTNC 530 HSCI
31.4 List of machine parameters
(Excerpt from the iTNC 530 HSCI Technical Manual of May 2011)
31.4.1 Format: Encoders and machines
MP Function and input Software
version and
behavior
MP10 Active axes
Input: %xxxxxxxxxxxxxxxxxx
Input: Bits 0 to 17 represent axes 1 to 18
0: Axis not active
1: Axis active
PLC
RUN
MP12 Axis-specific demo operation for NC axes
Format: %xxxxxxxxxxxxxxxxxx
Input: Bits 0 to 17 represent axes 1 to 18
0: Demo operation not active
1: Demo operation active
PLC
RUN
MP20 Monitoring functions for the axes
Format: %xxxxxxxxxxxxxxxxxx
Input: Bits 0 to 17 represent axes 1 to 18
0: Monitoring not active
1: Monitoring active
PLC
RUN
MP20.0 Absolute position of the distance-coded reference marks
MP20.1 Amplitude of encoder signals
MP20.2 Edge separation of encoder signals
MP21 Monitoring functions for the spindle
Format: %xx
Input: Bit 0 – Spindle 1
0: Monitoring not active
1: Monitoring active
Bit 1 – Spindle 2
0: Monitoring not active
1: Monitoring active
PLC
RUN
MP21.0 Absolute position of the distance-coded reference marks
MP21.1 Amplitude of encoder signals
MP21.2 Edge separation of encoder signals
MP100 Designation of axes
Format: -wvucbazyxWVUCBAZYX
Input: Characters 1 to 9 from the right represent axes 1 to 18
PLC
RUN
MP100.0 Traverse range 1
MP100.1 Traverse range 2
MP100.2 Traverse range 3
MP108.x Assignment of axes to drive-control motherboards
Input: 0 to 4: Number of drive-control motherboard in the HSCI chain
MP109.x Assignment of spindle(s) to drive-control motherboards
Input: 0 to 4: Number of drive-control motherboard in the HSCI chain
RESET
MP110.x Assignment of position encoder inputs to the axes
Input: 0: No position encoder input
1 to 6: Position encoder inputs X1 to X6
35 to 38: Position encoder inputs X35 to X38
201 to 214: Position encoder inputs X201 to X214
RESET
