31.4.10 Tool measurement with TT
MP Function and input Software
version and
behavior
MP6500 Tool measurement with TT 130
Format: %xxxxxxxxxxxxxxx
Input: Bit 0 – Cycles for tool measurement
0: Disabled
1: Not disabled
Bit 1 –
0: Tool radius measurement allowed. Tool length measurement with
rotating spindle
1: Tool radius measurement and individual tooth measurement disabled
Bit 2 –
0: Tool length measurement with stationary spindle (bit 1=1)
1: Tool length measurement with rotating spindle, only if a tool radius
offset (TT: R-OFFS) has been entered in the tool table
Bit 3 –
0: Tool measurement with spindle orientation
1: Tool measurement without spindle orientation. Individual tooth
measurement not possible. Tool radius measurement possibly faulty
Bit 4 –
0: Automatically determine speed
1: Always use minimum spindle speed
Bit 5 – NC stop during tool checking
0: The NC program is not stopped when the breakage tolerance is
exceeded
1: If the breakage tolerance is exceeded, the NC program is stopped
and the error message Tool broken is displayed.
Bit 6 – NC stop during tool measurement
0: The NC program is not stopped when the breakage tolerance is
exceeded
1: If the breakage tolerance is exceeded, the NC program is stopped
and the error message Touch point inaccessible is displayed.
PLC
RUN
MP6500 Tool measurement with TT 130
Format: %xxxxxxxxxxxxxxx
Input: Bit 7 – Reserved
Bit 8 – Probing routine
0: Probe contact is probed from several directions
1: Probe contact is probed from one direction
Bit 9 – Automatic measurement of the direction of the probe contact
basic rotation (bit 8 = 1)
0: Basic rotation is not measured
1: Basic rotation of the probe element is automatically measured
Bit 10 – Probing routine (bit 8 = 1)
0: Pre-positioning to starting point in all three principal axes
1: Pre-positioning to starting point in the tool axis and in the axis of the
probing direction (MP6505) (bit 9 = 0)
Bit 11 – Tool checking and changing in the tool table
0: After Tool checking the tool table is changed
1: After Tool checking the tool table is not changed
Bit 12 – PLC datum shift
0: Do not include
1: Include
Bit 13 –
0: Tool is measured in the tilt position in which the tool touch probe was
also calibrated
1: Tool is measured in another tilt position
Bit 14 – Tool measurement with number of teeth = 0
0: Tool measurement with rotating spindle
1: Tool measurement with stationary spindle
PLC
RUN
