7.5 Evaluation of the service files
The compressed service files cannot be viewed on the control.
8 Read out the ZIP file (e.g. service4CF4D383.zip) to an external data medium.
8 Decompress the ZIP file.
The compressed service file contains a large number of files. Some examples:
Not all service files can be evaluated by the service engineer himself. They serve primarily to
provide the machine manufacturer or a HEIDENHAIN service agency with comprehensive information
on an error that occurred on a machine.
Upon agreement, the ZIP file can be sent to the OEM or to HEIDENHAIN.
File Meaning Open with ...
(recommended)
$mdi.h Command lines for the operating mode Programming with manual data input Text editor
_hwstree.txt Information on hardware, firmware, HSCI bus addresses, etc, Text editor
xxx.mp Machine parameter list Text editor
bootprotocol.lis List of initialized processes Text editor
cpuinfo Features of the main computer Text editor
herosdiagnose.txt Information on the HeROS version, size of main memory, etc. Text editor
if0.cfg Ethernet IP address and subnet mask of the control Text editor
kinelist.tab Contents of the kinematics table Text editor
kinemat0.tab Description of (possible) machine kinematics Text editor
lb_act.log Contents of the log Text editor
ncdata.sys Information on EnDat positions, active preset tables, active kinematics,
handwheel, display mode, etc.
Text editor
ncpath.sys Information on the active tool table, active preset table and on the active
kinematics as well as on the NC program machined last, etc.
Text editor
meminfo Information on the main memory Text editor
plcmem.txt State of the PLC operands at the time the service file was generated Text editor
report.txt Information on the HSCI devices used Text editor
S_State.service.sco Oscillogram of selected signals TNCscopeNT
sik.info Information on the system identification key Text editor
times.sys Operating hours Text editor
Tnctime.sys Operating time of the control (Control on) Text editor
tool.t Tool table Text editor
tool_p.tch Pocket table Text editor
updatehistory.txt Log of NC software updates Text editor
<name>.h Milling program of the customer Text editor
Attention
Confidential data (e.g., customer's milling program) can be removed before the service file is sent
in ZIP format.
