HEIDENHAIN iTNC 530 HSCI Service Manual

18 – 246 HEIDENHAIN Service Manual iTNC 530 HSCI
18.3 PSL 130 low-voltage power supply unit
The PSL 130 power supply unit was especially designed to power HSCI components.
It provides two output voltages of 24 V each.
These two output voltages can also be connected in parallel and used as desired for NC or PLC supply.
Further information and connector layouts --> See ”Connector designations and pin layouts” on page
28 – 453.
Power consumption: max. 1000 W
Internal protection: 4 A
Output voltage of
PSL 130
Tolerance Insulation Output current
+24 V NC +/- 5 % Double insulation Max. 20 A
+24 V PLC Variations between 20 V and
28 V, depending on the load
Basic insulation Max. 20 A
Power supply for the PSL 130 Connection for PSL 130
power supply
HSCI components powered by
PSL 130
Phases L1 and L2
(400 Vac +/- 10%, 50 Hz)
X33  MC 6222
 MC 6241
 MB 620
 PLB 62xx
 PLB 61xx
DC-link voltage Uz
(400 Vdc to 750 Vdc)
Conductor bar
Note
The connection to X33 is obligatory, that to the conductor bar optional, though recommended by
HEIDENHAIN.
