D2 Drive User Guide v1.8 2. Specifications
HIWIN Mikrosystem Corp. 10
2.2. Drive specifications
Table 2-2 Drive specification
Basic specifications
Input power
220V
Main power
Frame
A-C
Single/three-phase, 200 - 240 Vac 50/60Hz
Frame
D
Three-phase, 200 - 240 Vac 50/60Hz
Control
power
Frame
A-D
Single-phase, 200 - 240 Vac 50/60Hz
Output power
Power
Frame A: 100 W; frame B: 400 W; frame C: 1.0 KW;
frame D: 2.0 KW.
Continuous current
Frame A: 0.9 A
rms
; frame B: 2.5 A
rms
;
frame C: 5.1 A
rms
; frame D: 11 A
rms
.
Peak current
Frame A: 2.7 A
rms
; frame B: 7.5 A
rms
;
frame C: 15.3 A
rms
; frame D: 33 A
rms
.
Sustainable duration
of peak current
1 second maximum.
Environment
Temperature
Operation temperature: 0°C to 45°C
(if over 55°C, the forced ventilation is needed)
Storage temperature: -20°C to 65°C
Humidity
0 to 90% RH (non-condensing)
Altitude
Below 1,000 meters
Vibration
1G (10 to 500Hz)
Installation pollution level
II
Control method
IGBT PWM space vector control
Encoder input
Resolution/Feedback
resolution
13-bit (10,000 count/rev) less-wire incremental encoder;
17-bit (131,072 count/rev) serial incremental encoder (5
lines).
Frequency
5M pulse/sec (Before Quadrature);
20M count/sec (After Quadrature).
Other
For the dual-loop model, the rotary encoder should be the
17-bit serial absolute encoder and the linear encoder
should be the digital AqB encoder.
Parallel I/O
connector
Control signal
Input
9 (general purpose) for D2 model
10 (general purpose) for D2T model
Output
4 (general purpose) for D2 model
5 (general purpose) for D2T model
Analog signal
Input
1 (12-bit A/D)
Output
2 (analog monitor: 2 outputs)
Pulse signal
Input
2 (low-speed channel, high-speed channel)
Output
4 (line driver: 3 outputs; open collector: 1 output)
Brake
connector
Control signal
Output
Used to connect with brake (1 Adc max). Also, it is
programmable for general-purpose output.
Dynamic brake
Frame D model has one built-in dynamic brake resistor
(line resistance: 2.6 Ω ± 5%; continuous power: 120 W;
peak power: 600 W).
Communication function
USB
Used to connect with PC, 115,200 bps
Front panel
LCD status display: dot matrix 8*2 characters with 4
buttons;
LED status indicator lights (green, red)
