D2 Drive User Guide v1.8 D. Modbus Communication
HIWIN Mikrosystem Corp. 285
D.3. Modbus objects
The data type of Modbus object is listed in the following table.
Table D-12
Code
Data type
Range
INT16
Signed 16 bit
-32,768 to +32,767
INT32
Signed 32 bit
-2,147,483,648 to +2,147,483,647
UINT16
Unsigned 16 bit
0 to 65,535
UINT32
Unsigned 32 bit
0 to 4,294,967,295
REAL32
Float 32 bit
--
D.3.1. Input register
The data length of each readable input register is 32 bits.
Table D-13
Object
Register
address
Description
Type
Unit
1
0x0000
Feedback position
Lower data
INT32
counts
0x0001
Higher data
2
0x0002
Reference position
Lower data
INT32
counts
0x0003
Higher data
4
0x0006
Position error
Lower data
INT32
counts
0x0007
Higher data
10
0x0012
Feedback velocity
Lower data
REAL32
count/s
0x0013
Higher data
11
0x0014
Reference velocity
Lower data
REAL32
count/s
0x0015
Higher data
12
0x0016
Velocity error
Lower data
REAL32
count/s
0x0017
Higher data
30
0x003A
Actual current
Lower data
REAL32
A
amp
0x003B
Higher data
31
0x003C
Command current
Lower data
REAL32
A
amp
0x003D
Higher data
40
0x004E
Analog command
Lower data
REAL32
mV
0x004F
Higher data
41
0x0050
Bus voltage
Lower data
REAL32
V
0x0051
Higher data
51
0x0064
Soft-thermal accumulator
Lower data
REAL32
%
0x0065
Higher data
53
0x0068
Average load ratio
Lower data
REAL32
%
0x0069
Higher data
54
0x0070
Peak load ratio
Lower data
REAL32
%
0x0071
Higher data
55
0x0072
Current effective value
Lower data
REAL32
A
amp
0x0073
Higher data
61
0x0078
Status 5
Lower data
UINT32
--
0x0079
Higher data
81
0x00A0
Status 4
Lower data
UINT32
--
0x00A1
Higher data
90
0x00B2
Status 6
Lower data
UINT32
--
0x00B3
Higher data
91
0x00B4
Status 0
Lower data
UINT32
--
