D2 Drive User Guide v1.8 7. LCD Operation
HIWIN Mikrosystem Corp. 206
7.5. Change parameters page
The third page of LCD is the change parameters page, which is used to change the set
parameter. The operation can be divided into two zones: common parameter zone and
advanced parameter zone. The former is given in Table 7-8 and the latter is given in Table
7-9. In the change parameters page, press the Up key or Down key to change the edited
parameter. The operation flow chart is described in Fig. 7-7. The detailed operation procedure
is described in the next subsection (take the LCD abbreviated display symbol as an example).
Fig. 7-7 Operation flow chart for change parameters page
(a) LCD abbreviated display symbol
(b) LCD numbered display symbol
Deceleration
setting.
Speed setting.
3:SAVEFL
NO
3:No.000
2000
3:No.001
2000
3:No.003
500
3:No.340
0
3: +++
0
•
•
•
Common parameter zone
Advanced parameter
zone
Press to enter
the advanced
parameter zone.
Note. Static cursor (flashing underscore). The parameter can be edited.
3 SAVEFL
NO
3 000
2000
Save parameters
in the drive’s RAM
to flash.
Acceleration
setting.
Static
cursor
ZeroTune
load level.
3 001
2000
3 003
500
3 340
0
3 +++
0
•
•
•
Common parameter zone
Advanced parameter zone
