D2 Drive User Guide v1.8 4. Wiring
HIWIN Mikrosystem Corp. 60
4.4. Multiple drives connection
Caution: Do not use the power connector on the drive to connect the power supply between
drives in parallel.
Fig. 4-24
mega-fabs
D2 Series drive
CN1
L1
L2
L3
L1C
L2C
NFB
Filter
KM
KM
ON
OFF
Emergency
Stop
KM
SK
3-phase
200~240VAC
50/60Hz
Earth
mega-fabs
D2 Series drive
CN1
L1
L2
L3
L1C
L2C
mega-fabs
D2 Series drive
CN1
L1
L2
L3
L1C
L2C
Terminal
Terminal
Terminal
