Roche Diagnostics
B-30
Operator’s Manual · Version 3.4
5 Daily operation Cedex Bio analyzer
Preparing the system
16
On the screen with the reagent set buttons, press the button for the set you just
inserted.
A screen is displayed that shows details of the set.
The status description points to the action you need to take. If you just inserted a
reagent set, you may have to perform the initial calibration and QC.
17
Press .
18
When you have finished adding and replacing reagent sets, press to
proceed to the next stage in the Prepare wizard.
Preparing cuvettes
Cuvettes are supplied and handled in cuvette segments. Each segment contains ten
cuvettes. The segments are placed on the cuvette ring of the rotor.
e
For information on cuvette segments, see Cuvette segments on page A-55.
For information on the cuvette ring, see Cuvette ring on page A-59.
Each segment on the cuvette ring is represented by a button on the screen.
A Status description
Figure B-7
When handling the reagent sets without using the Prepare wizard:
Choose Overview > .
Make sure that you have read and understood section Safety information on page B-5. The
following warning messages in particular are relevant:
o Personal injury or damage to the analyzer due to contact with analyzer mechanism on
page B-5.
o Infection by waste solution on page B-5.
