Roche Diagnostics
B-140
Operator’s Manual · Version 3.4
6 Special operations Cedex Bio analyzer
Adjusting the touchscreen
Adjusting the touchscreen
With a touchscreen, it is important that the point where you press the screen
corresponds exactly with its hardware equivalent. If this were not the case, pressing a
screen item such as a button might not lead to the expected result.
a To adjust the touchscreen
1
Press the global button.
A screen is displayed that offers several kinds of stopping. Ignore it.
2
Press the global button again.
A screen for adjusting the screen is displayed.
3
Press exactly in the center of the red cross.
When you have touched it properly the cross disappears and the next red cross is
displayed.
4
Do the same for all crosses.
5
When all crosses have been confirmed, a new message is displayed, informing you
that you need to reboot the system before the new calibration values take effect.
6
Press to close the calibration screen.
If you are unable to press , you must switch off the analyzer directly using
the green mains button. Restart the analyzer afterwards.
7
Restart the system.
o Press
.
o Press Restart.
The system shuts down and automatically restarts.
o Wait until the Overview tab is displayed and the system is in Standby status.
