Hardware overview
Cuvette ring
The cuvette ring holds up to 6 cuvette segments, each containing 10 cuvettes.
Cuvettes fit neatly in the cuvette ring, without touching the walls when being moved
along the ring.
e
See Preparing the reagents on page B-24.
See maintenance action Clean reagent disk and sample area on page D-14.
Barcode scanner
A hand-held barcode scanner is used for reading barcoded labels.
A Cuvette ring B Cuvette segment
Figure A-29 Cuvette ring
Loss of sight
The intense light of the LEDs may severely damage you eyes. Do not stare into the LEDs.
Scanning equipment using LED technology is covered by the international standard
EN/IEC 60825-1 LED Safety: Class 1.
A Barcode scanner B Scanner connector on the analyzer
Figure A-30 Hand-held barcode scanner
