Cedex Bio analyzer 3Hardware
Hardware overview
Connectors
A Power supply for main instrument
B Data and communication connectors
C Fluid connectors
D Front USB port (not shown)
E Host interface connector
F Barcode scanner connector
G External LAN cable (Do not remove the
cable.)
H USB 2 connector
I Water connector
J Cleaner connector
K Waste connector
Figure A-33 Connectors
B
C
A
D
A
E
F
G
H
I J K
