en
1 690 386 081 2018-02-22| Robert Bosch GmbH
16 | EL–52425 |
en – Contents
1. Symbols used 17
1.1 In the documentation 17
1.1.1 Warning notices -
Structure and meaning 17
1.1.2 Symbols in this documentation 17
1.2 On the product 17
2. User instructions 17
2.1 Important information 17
2.2 Target group 17
2.3 Safety information 17
3. Product description 18
3.1 Intended use 18
3.2 Measurement bay prerequisite 18
3.3 Scope of delivery / Special accessories 18
3.4 EL–52425 18
4. Installation 19
4.1 Base frame 19
4.2 Column 19
4.3 End stop 20
4.4 Tape measure mounting 20
4.5 Mount for precision holder 20
5. Operation 21
5.1 Alignment 21
5.2 Alignment example 21
5.3 Aligning the EL–52425 through vehicle
longitudinal center plane 23
5.4 Aligning the precision holder 23
5.5 Tape measure / mounting 24
5.6 Aligning the EL–52425 by setting aid 24
5.7 Adjusting the height of the calibration board 24
5.8 Adjusting the height of the calibration board 25
5.8.1 with ruler mounting (optional) 25
5.8.2 Reading out the height 25
5.9 Attaching the calibration board 26
6. Maintenance 26
6.1 Ultrasonic cleaning 26
6.2 Check 26
6.3 Checking with a spirit level 26
7. Spare parts 27
8. Calibration boards 27
9. Decommissioning 27
9.1 Changing location 27
9.2 Temporary shutdown 27
9.3 Disposal and scrapping 27
10. Technical specifications 27
en
