Symbols used | EL–52425 | 17
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices -
Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the con-
sequences of the hazard as well as preventive action.
Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of failu-
re to observe action and information given.
¶ Hazard prevention action and information.
The key word indicates the likelihood of occurrence and
the severity of the hazard in the event of non-observan-
ce:
Key word Probability of
occurrence
Se
verity of danger if ins-
tructions not observed
DANGER Immediate impen-
ding danger
Death
or severe injury
WARNING Possible impending
danger
Death
or severe injury
CAUTION Possible dangerous
situation
Minor
injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several steps.
e
One-step
operation
Instruction consisting of one step.
Intermediate
result
An instruction produces a visible inter-
mediate result.
"
Final result There is a visible final result on com-
pletion of the instruction.
1.2 On the product
!
Observe all warning notices on products and ensure
they remain legible.
en
2. User instructions
2.1 Important information
Before commissioning, connecting and operating
Bosch products, it is absolutely essential to read the
entire operating instructions carefully, especially the
safety instructions. By doing so, any uncertainties
in handling Bosch products and associated risks are
avoided in the interests of your own safety and of pre-
venting damage to the products. If a Bosch product
is handed over to another user, the operating instruc-
tions, the safety instructions and the information on
the intended use must be handed over as well.
2.2 Target group
The product may be used only by skilled and instruc-
ted personnel. This requires reading the operating
instructions and the passenger car manufacturer's
repair manual beforehand.
Only technicians or workshop personnel are allowed
to use the product in service locations.
2.3 Safety information
WARNING – Risk of the EL–52425 tipping
over due to overloading.
¶ Only attach the approved targets and
the approved P-AssistS5 laser unit.
¶ Do not attach more than the specified
number of targets.
