– Remove the turning over tool and install the lower timing chain
cover. Refer to ⇒ page 109 .
Note
Tighten the bolts -1 and 4- with an additional turn after installing
the vibration damper. The bolts must be removed again to install
the vibration damper.
– Install the vibration damper. Refer to
⇒ 1.4 Vibration Damper, Removing and Installing, page 47 .
– Install the upper timing chain cover. Refer to
⇒ 2.2.1 Upper Timing Chain Cover, Removing and Installing,
page 106 .
– Install the ribbed belt tensioning damper. Refer to
⇒ 1.3 Ribbed Belt Tensioner, Removing and Installing, page
47 .
– Install the ribbed belt. Refer to
⇒ 1.2 Ribbed Belt, Removing and Installing, page 46 .
The rest of the installation is performed in reverse order of re‐
moval, noting the following:
– After performing work on the chain drive the adaptation value
in the Engine Control Module (ECM) must be adapted. To do
this turn on the ignition and select the following menu items on
the Vehicle Diagnostic Tester :
♦ 01 - Engine Electronics
♦ Guided Functions
♦ 01 - Adaptation After Repair Work On the Chain
Drive
Tightening Specifications
♦ Refer to
⇒ 3.1 Overview - Camshaft Timing Chain, page 114 .
♦ Refer to
⇒ 3.2 Overview - Balance Shaft Drive Chain, page 116 .
♦ Refer to ⇒ Body Exterior; Rep. Gr. 66 ; Noise Insulation;
Overview - Noise Insulation .
3.4 Balance Shaft Drive Chain, Removing
and Installing
The procedure Balance shaft drive chain removing and installing
is in the Camshaft timing chain removing and installing proce‐
dure. Refer to
⇒ 3.3 Camshaft Timing Chain, Removing and Installing,
page 118 .
3.5 Chain Length, Checking
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Plug - Lower Timing Chain Cover
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
130 Rep. Gr.15 - Cylinder Head, Valvetrain
