– Coat the new O-rings -4- with coolant.
– Install the connection pieces -2- into the engine oil cooler -1-.
– Press the accessory assembly bracket with the engine oil
cooler -1- onto the connection, mount the bolts and tighten.
Refer to
⇒ Fig. Accessory Assembly Bracket - Tightening Specifica‐
tions and Tightening Sequence , page 45 .
– Install the A/C compressor. Refer to ⇒ Heating, Ventilation
and Air Conditioning; Rep. Gr. 87 ; A/C Compressor; Over‐
view - A/C Compressor Power Unit .
– Install the generator. Refer to ⇒ Electrical Equipment; Rep.
Gr. 27 ; Generator; Generator, Removing and Installing .
– Install the ribbed belt. Refer to
⇒ 1.2 Ribbed Belt, Removing and Installing, page 46 .
– Fill with coolant. Refer to ⇒ page 218 .
– Install the oil filter and then check the oil level. Refer to ⇒ Main‐
tenance ; Booklet 36.1 ; Procedure Descriptions; Engine Oil,
Draining, Replacing Oil Filter, and Filling .
Tightening Specifications
♦ Refer to
⇒ 1.1 Overview - Cylinder Block, Belt Pulley Side, page 44 .
♦ Refer to ⇒ 2.1 Overview - Timing Chain Cover, page 104 .
♦ Install the oil filter and then check the oil level. Refer to ⇒ Main‐
tenance ; Booklet 36.1 ; Procedure Descriptions; Engine Oil,
Draining, Replacing Oil Filter, and Filling .
1.6 Engine Support, Removing and Instal‐
ling
Removing
Special tools and workshop equipment required
♦ Engine Support Bridge - Spindle - 10-222A/11-
– Remove the engine bracket. Refer to
⇒ 2.2 Engine Mount, Removing and Installing, page 30 .
– Lift the engine using the Engine Support Bridge - Spindle -
10-222A/11- -1- to dimension -a-.
• Dimension -a- = approximately 30 mm.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
1. Cylinder Block, Belt Pulley Side 55
