– Guide the Puller - T10133/2A- in the groove on the fuel injec‐
tor.
– Install the Removal Tool Injector/Combustion Chamber Seal
Tool Set - 16A - T10133/16A- .
– Remove the fuel injector by using the torque wrench -1- to turn
the bolt.
– If the tightening specification limit of »5 Nm« is achieved with‐
out the fuel injector loosening, remove the puller and loosen
the fuel injector with the sleeve.
Note
♦
The fuel injectors may be damaged if the tightening specifica‐
tions are not observed.
♦
The combustion chamber seal must always be replaced be‐
fore installing the fuel injector. Refer to
⇒ 2.4 Fuel Injector Seals, Replacing, page 288 .
– Replace combustion chamber seal and install fuel injector.
Refer to ⇒ 2.4 Fuel Injector Seals, Replacing, page 288 .
2.3 Intake Manifold-Fuel Injectors, Remov‐
ing and Installing
Note
Vehicles with the engine codes CNTA do not have an intake
manifold-fuel injector.
Removing
– Remove the fuel return hose -1- from the intake manifold.
– Disconnect the connectors -3- from the mount.
– Disconnect the connectors -4 and 5-.
– Free up the wiring harness -1- from the fuel rail.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
2. Fuel Injectors 287
