3.2 Crankshaft Dimensions
(Dimensions in mm)
Reconditioning
Dimension
1)
Crankshaft Bearing
Pin Diameter
Connecting Rod
Bearing Pin Diame‐
ter
Basic dimension 58.00 47.80
1)
The preparation of worn crankshafts is not provided.
3.3 Main Bearing Shells Allocation
The bearing shells are allocated to the cylinder block with the
correct thickness at the factory. Colored spots serve to identify
the bearing thicknesses.
The code letters on the lower contact surface or on the top of the
cylinder block identify which bearing shell and where it must be
mounted on the cylinder block (upper bearing shell).
The code letters on the crankshaft identify which bearing shells
and where they must be installed in the bearing cover (lower
bearing shell).
The first letter is for bearing cover one, the second for bearing
cover two, etc.
Cylinder Block Bearing Shell Identification:
Note
The cylinder block identification may be located either on the oil
pan sealing surface or on the top (transmission side) of the cyl‐
inder block.
The identification on the cylinder block is for the upper bearing
shell.
– Write down the letters and then use the table to find the color
identification.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
64 Rep. Gr.13 - Crankshaft, Cylinder Block
