– Remove the bolts -arrows- and engine mount -1-.
Installing
Install in reverse order of removal. Note the following:
– Check the adjustment of the assembly mounts. Refer to
⇒ 2.7 Subframe Mount, Checking Adjustment, page 37 .
Tightening Specifications
♦ Refer to ⇒ 2.1 Overview - Subframe Mount, page 29
2.3 Transmission Mount, Removing and In‐
stalling
Removing
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Bolts - Transmission Mount
– Remove the battery tray. Refer to ⇒ Electrical Equipment;
Rep. Gr. 27 ; Battery; Battery Tray, Removing and Installing .
– Remove the Engine Control Module - J623- from the bracket.
Refer to
⇒ 6.1 Engine Control Module J623 , Removing and Instal‐
ling, page 321 .
– Remove the bolts -arrows- and remove the bracket -1-.
Note
Depending on the version different brackets are installed.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
2. Subframe Mount 31
