– Insert the Flywheel Retainer - 3067- into the hole in the cylin‐
der block -A-.
Tightening Specifications
♦ Refer to
⇒ 2.1 Overview - Cylinder Block, Transmission Side,
page 57 .
2.3 Sealing Flange, Removing and Instal‐
ling, Transmission Side
Special tools and workshop equipment required
♦ Seal Installer - Sealing Flange Guide Sleeve - T20097-
♦ Hand drill with brush attachment
♦ Protective eyewear
♦ For the correct sealant. Refer to the Parts Catalog.
Removing
• The transmission is removed.
– Remove the flywheel. Refer to
⇒ 2.2 Flywheel, Removing and Installing, page 58 .
– Unhook the intermediate plate at sealing flange and at the
alignment sleeves -arrows-.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
2. Cylinder Block, Transmission Side 59
