10 - Nut
Tightening specification and sequence. Refer to
⇒ Fig. Catalytic Converter - Tightening Specification and Sequence , page 349 .
11 - Nut
❑ 30 Nm
12 - Front Clamping Sleeve
❑ Before tightening, align exhaust system free of tension. Refer to
⇒ 1.4 Exhaust System, Installing without Tension, page 345 .
❑ Installed position. Refer to ⇒ 1.6 Clamping Sleeve Installation Position, page 347
❑ Tighten threaded connections evenly.
– Install the clamping sleeve in the shown position. The threa‐
ded connection -arrows- must not project over the lower edge
of the clamp.
Installed Location of the Catalytic Converter Screw Clamp
– Install the screw-type clamp in the shown position. The threa‐
ded connection -arrow- must have equal distance to the other
components.
Catalytic Converter - Tightening Specification and Sequence
– Tighten the threaded connections in steps in the sequence
shown:
Step Threaded Con‐
nections/Nuts
Tightening Specification
1. -1, 3 and 4- Install all the way in by hand.
• It must be possible to slide the cat‐
alytic converter and bracket back
and forth.
2. -2- 15 Nm Note the installation position.
Refer to
⇒ Fig. Installed Location of the Cat‐
alytic Converter Screw Clamp , page
349 .
3. -1, 3 and 4- 20 Nm
2.2 Catalytic Converter, Removing and In‐
stalling
Special tools and workshop equipment required
♦ Hot bolt paste. Refer to the Parts Catalog.
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
2. Emissions Control 349
