Bearing Cap Bearing Shell Identification:
The identification on the crankshaft is for the lower bearing shell.
– Write down the letters and then use the table to find the color
identification.
S = Black
R = Red
G = Yellow
B = Blue
W = White
3.4 Crankshaft Needle Bearing, Replacing
Only for Vehicles Equipped with a Twin Clutch Transmission
Special tools and workshop equipment required
♦ Counter-support for example Puller - Kukko Counterstay -
22/1-
♦ Internal puller, for example Puller - Kukko Internal - 14-19mm
- 21/2-
♦ Bearing Installer - Bearing Press Piece - VW207C-
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Bearing - Crankshaft Needle
Conditions
• Always replace the needle bearing -arrow- after the engine
and transmission are separated.
• The front edges of the internal puller must not be broken off.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
3. Crankshaft 65
