❑ If the connection was loosened, it must be replaced.
12 - Fuel Supply Line
13 - Spring Clamp
❑ Replace after removing
7.2 High Pressure Pump, Removing and In‐
stalling
Special tools and workshop equipment required
♦ Flare Nut Attachment - 17mm - T10456-
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Bolts - High Pressure Pump
Note
♦
Only remove the high pressure pump when the engine is cold.
♦
Pay attention when installing the high pressure pump, that no
dirt enters the fuel system.
♦
Collect escaping fuel with a rag.
♦
Inspect the O-ring for the high pressure pump, and replace it
if damaged.
♦
If the connection for the high pressure line -item 11-
⇒ Item 11 (page 327) was loosened, it must be replaced.
♦
Lubricate the high pressure line with engine oil and always
fasten them free of tension.
♦
Vehicles with the engine codes CNTA do not have an intake
manifold-fuel injector.
CAUTION
Fuel system is under high pressure.
Risk of injury from fuel spraying out.
– Reducing the fuel high pressure.
Removing
– Remove the engine cover. Refer to
⇒ 3.1 Engine Cover, Removing and Installing, page 38 .
– Remove the air filter housing -3-. Refer to
⇒ 3.2 Air Filter Housing, Removing and Installing,
page 294 .
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
328 Rep. Gr.24 - Multiport Fuel Injection
