9 - Bolt
❑ 4 Nm 45°
❑ Replace after removing
Balance Shaft Pipe - Installed Position
The openings -arrow- must face the chain side.
4.2 Balance Shaft, Removing and Installing
⇒ 4.2.1 Balance Shaft Intake Side, Removing and Installing,
page 70 .
⇒ 4.2.2 Balance Shaft Exhaust Side, Removing and Installing,
page 73 .
4.2.1 Balance Shaft Intake Side, Removing
and Installing
Balance shaft and needle bearing must be replaced after every
removal. Install a new needle bearing with the same color identi‐
fication
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Balance Shaft - Intake Side
♦ Bearing - Needle Rim
♦ Bolt - Intake Side Balance Shaft
♦ Bolt - Intermediate Sprocket
♦ O-ring - Intermediate Shaft
♦ Sprocket - Intermediate
Removing
• Engine removed.
– Remove the toothed belt from the coolant pump. Refer to
⇒ 2.8 Coolant Pump Toothed Belt, Removing and Installing,
page 235 .
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
70 Rep. Gr.13 - Crankshaft, Cylinder Block
