3 Engine Cover
⇒ 3.1 Engine Cover, Removing and Installing, page 38 .
3.1 Engine Cover, Removing and Installing
Removing
– Carefully pull the engine cover off the bolts one after the other
in direction of -arrows-. Do not remove the engine cover on
one side or in a jerking manner.
Installing
– In order to prevent causing damage, do not hit the engine cov‐
er with your fist or tool.
– Position the engine cover while paying attention to the oil filler
tube and oil dipstick.
– Press the engine cover into the rubber grommets on the left
side first, then into the ones on the right side.
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
38 Rep. Gr.10 - Engine Assembly
