– Remove the Oil Pressure Switch -1-.
Installing
Note
To prevent oil loss, insert the Oil Pressure Switch - F1- in the
opening immediately.
Install in reverse order of removal. Note the following:
– Check the oil level. Refer to ⇒ Maintenance ; Booklet 36.1 ;
Procedure Descriptions; Engine Oil Level, Checking .
Tightening Specifications
♦ Refer to
⇒ 4.2 Overview - Oil Pressure Switch/Oil Pressure Regulator
Valve, page 198 .
4.4 Reduced Oil Pressure Switch - F378- ,
Removing and Installing
Special tools and workshop equipment required
♦ Socket and Jointed Extension - 24mm - T40175-
Caution
This procedure contains mandatory replaceable parts. Refer
to component overview prior to starting procedure.
Mandatory Replacement Parts
♦ Seal - Reduced Oil Pressure Switch
Removing
Note
♦
Place a cloth under the accessory assembly bracket to collect
leaking engine oil.
♦
Replace the seal after each time the oil pressure switch is
loosened.
– Disconnect the electrical connector -arrow- on the Reduced
Oil Pressure Switch - F378- .
Golf 2015 ➤ , Golf Variant 2015 ➤
Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
200 Rep. Gr.17 - Lubrication
