6-2 DELTA/DELTA XL/KAPPA VF8

6 T

RENDS

Overview

The monitor stores trend data for all connected signals except for pressures labeled

P1a-d, P2a-d, P3a-d, which are automatically assigned as temporary labels when

pressure transducers are initially connected. You can request a trend recording or

report and execute a print screen of displayed trends. The monitor deletes all trend

data once the patient is discharged.

You can store a currently displayed trend screen in the Event Recall Database by

pressing the

Mark fixed key on the front of the monitor. Manually and

automatically stored events are identified on an event summary bar at the top of the

trend display as outlined below:

 Trend Table – An icon ( ) over time line marks manually stored events

only; alarms and arrhythmia calls are not marked (see illustration on page 6-6)

 Trend Graphs – A small yellow vertical line marks manually and

automatically stored events (see illustration on page 6-4).

For information on marking or storing events (including use of the

Mark fixed key

and the Event Recall screen), see page 1-26.

Trend Setup

The Trend Setup menu allows you to customize trend functions.

To access the Trend Setup menu

1. Click on the Menu fixed key on the front of the monitor.

2. Click on

Monitor Setup.

3. Click on

Trend Setup to display the Trend Setup menu.
