26-18 DELTA/DELTA XL/KAPPA VF8
26 P
ULSE CONTOUR CARDIAC OUTPUT (PICCO) MONITORING
Quick Reference – PiCCO Setup
Available functions, present on Pulse Contour parameters setup menu, are described in
the following table.
Pulse Contour Parameters Setup Menu
Menu Item Description Available Settings
Show All
Parameters
Displays all the PiCCO (continuous
and discrete) parameters in a
separate window.
Not applicable
Parameters Setup Allows user to designate which
parameter displays as Parameter 1,
Parameter 2, and Parameter 3.
Parameter 1:
PCCI (default),
PCCO, p-SV, p-SVI, p-SVR, p-
SVRI, SVV, PPV, dPmax
Parameter 2:
p-SVRI (default),
PCCO, PCCI, p-SV, p-SVI, p-
SVR, p-SVRI, SVV, PPV, dPmax
Parameter 3
SVV (default),
PCCO, PCCI, p-SV, p-SVI, p-
SVR, p-SVRI, PPV, dPmax
PiCCO Mini Trend Designates which parameter will be
trended for Mini Trend.
PCCI (default),
PCCO, p-SV, p-SVI, p-SVR, p-
SVRI, SVV
Catheter type Read-only field. Displays the
catheter type in use.
NOTE: Other is displayed if the
catheter that is connected requires
manual entry of an ACC value.
Selecting Other displays a key pad
for manual entry.
PV2013L07, PV2014L08,
PV2014L16, PV2014L22,
PV2015L20, PV2014L50, Other
Catheter Position Selects the position of the catheter.
NOTE: The selection Radial artery
is only visible when the catheter
PV2014L50 is connected.
Femoral artery, Axillary artery,
Brachial artery, Radial artery
NOTE: When a patient is initially
admitted, this field displays ‘---’
until the catheter position is
selected.
CAUTION: Confirm that the
selected catheter position is
accurate before starting a
measurement. Changing the
catheter position after starting a
measurement, has no effect on the
current measurements. To correct
the catheter position, discharge
and readmit the patient.
