PATIENT P REPARATION
VF8 DELTA/DELTA XL/KAPPA 8-11
TruST Setup
You can select electrode configuration according to TruST twelve-lead format. TruST
twelve-lead monitoring is available Delta/Delta XL/Kappa only if you are using the
MultiMed 6-lead pod. If a five or twelve-lead pod is connected, the TruST 12-lead
selection is ghosted and unavailable.
To select TruST configuration:
1. Click on the HR parameter box.
2. Click on
ECG Options.
3. Scroll to
TruST 12-Lead and select ON.
Twelve-Lead Configurations (Standard and Frank)
You can select electrode configuration according to Standard or Frank Lead format.
Twelve-lead monitoring is available only if you are using the MultiMed 12-lead pod.
To select 12-lead configuration
1. Click on the HR parameter box.
2. Click on
Lead Setup.
3. Scroll to
12 Lead Position and select Standard or Frank.
Illustrations and guidelines for Frank and Standard lead configuration are provided on
the following pages.
NOTE: MultiMed 12-lead pod does not support Respiration.
