CONFIGURING THE MONITOR
VF8 DELTA/DELTA XL/KAPPA 2-3
Quick Reference – Main Menu Setup
The Main Menu
Menu Item Description Available Settings
Cursor Tool Provides access to the Cursor Tool
submenu (see below), which allows you
to select three waveforms displayed with
horizontal cursors and a vertical cursor.
•Setup
• Horizontal Cursor
•Stop
•Hemo/Calcs
• Vertical Cursor
The Cursor Tool Submenu
Setup Opens Cursor Tool setup menu. • Waveform (up to 3)
NOTE: In 4-channel mode, a maximum
of 2 waveforms are available.
• Sweep Speed
• 6.25 mm/sec
• 12.5 mm/sec
• 25 mm/sec (Default)
• 50 mm/sec
Horizonta
l
Cursor
(One for each
waveform on
display)
Displays a horizontal cursor. User can
scroll up and down each waveform.
NOTES:
• Cursor value is displayed
1
.
• Cursor and value remain displayed until
the window closes.
• Buttons remain ghosted until you press
the Stop key.
To exit the cursor tool:
• Press/click the rotary knob to exit the
cursor control.
or
• Press the Main Screen fixed key.
Not applicable
Stop Stops scrolling of all waveforms in the
cursor tool display and makes the
Horizontal and Vertical Cursor buttons
selectable.
Not applicable
Hemo/Calcs Opens the hemo/calcs screen.
NOTES:
• The button is ghosted unless a license
is present.
• The advanced calcs menu is available if
the option is installed.
Not applicable
1
The cursor value is displayed only if a scale is associated with the waveform. Waveform scales
are the same as parameter main display.
