ECG LEADS
VF8 DELTA/DELTA XL/KAPPA 8-15
ECG Leads
The number of available ECG leads depends on the type of pod and cable set you are
using, as shown in the following tables.
Regular ECG Leads
TruST 12-Lead
ECG Pod Cable Set Channels Leads Available
NeoMed 3-lead ECG1 I or II or III
MultiMed 5 3-, 5-lead ECG1, ECG2, ECG3
1
I, II, III, aVR, aVL, aVF, V
2
MultiMed 6 3-, 5-, 6-lead ECG1, ECG2, ECG3
1
I, II, III, aVR, aVL, aVF, V, V+
2
MultiMed 12 5-, 6-, 12-lead ECG1, ECG2, ECG3
1
I, II, III, aVR, aVL, aVF,
V1-V6
2
1
ECG3 is available only when HR, ARR, and ST parameter boxes are on the main screen.
2
V and V+ are chest leads; aVR, aVL, and aVF are augmented leads.
ECG Pod Cable Set Channels Leads Available
MultiMed 6 6-lead ECG1
3
I, II, III, aVR, aVL, aVF, V
1
, V+
1
, V2
2
,
V5
2
ECG2
3
I, II, III, aVR, aVL, aVF, V
1
, V+
1
, V2
2
,
V5
2
ECG3 I, II, III, aVR, aVL, aVF, V
1
, V+
1
,
dV1
2
, V2
2
, dV3
2
, dV4
2
, V5
2
, dV6
2
NOTE: TruST leads are indicated by a
prefix “d” before the V lead.
12-Lead
1
- -
Cable Type
1
- -
1
Selection unavailable/ghosted when TruST 12-Lead is set to ON.
2
Selection unavailable/ghosted when TruST 12-Lead is set to OFF.
3
Channel does not support display of any TruST leads.
