RADIOMETER MICROGAS 7650 MONITOR
VF8 DELTA/DELTA XL/KAPPA 28-19
Radiometer MicroGas 7650 Monitor
The Radiometer MicroGas 7650 monitor measures tpO
2
and tpCO
2
data. The data
from the MicroGas 7650 monitor is acquired through an MIB interface. This data is
displayed in a non-configurable tpO2 and tpCO2 parameter box.
A waveform channel is not displayed for the
MicroGas 7650 monitor's data. There are also no site
timers and no alarms.
The tpO
2
and tpCO
2
entries in the Alarm Limits
menu disappear when the MicroGas 7650 monitor is
connected. These entries do not reappear until this
MIB device is removed and a tpO
2
and tpCO
2
pod is
reconnected.
If you click the tpO
2
and tpCO
2
parameter box, the setup menu displays with the text
“No user selections.”
MIB tpO
2
and tpCO
2
trends appear in the trend/graph table similar to the tpO
2
and
tpCO
2
pod parameters (see page 6-3).
Aspect A-2000 BIS

Monitor
The Bispectral Index (BIS) is a continuously processed EEG parameter that measures
the state of the brain during the administration of anesthetics and sedatives. The
Aspect Medical BIS monitor A-2000 is connected to the bedside monitor via an MIB
interface. BIS and its associated parameters are trended and available for display on
the bedside monitor.
NOTE: The Radiometer MicroGas 7650 monitor is only supported on MIB II
hardware.
NOTE: For information about the BIS parameters, see documentation provided with
the Aspect A-2000 BIS Monitor.
Label Parameters Supported Units
BIS Bispectral Index -
SQI Signal Quality Index %
EMG Electromyography Power (70-110 Hz) dB
BSR Burst Suppression Ratio %
