STATUS M ESSAGES
VF8 DELTA/DELTA XL/KAPPA 11-9
Status Messages
EEG Mini
Trend
Allows you to select parameters for
display in mini-trends (see page 6-7
for more information on mini-trend
display)
1) Press the Fast Access fixed key.
2) Click on Split Screen.
3) Click on 10 Min Trends or 60 Min
Trends.
4) Open the EEG menu as described on
page 11-6.
5) Click on the setting of your choice:
Med, SEF, BSR, Power, Beta, Alpha,
Theta, or Delta
SEF Setting Determines Spectral Edge Frequency
(SEF) level
• 75, 85, 90, 95, 97, or 98 %
Low Filter
1, 2
Allows user to compensate for
excessive baseline drift.
• 0.5 Hz (Default)
• 1.0 Hz
High Filter
1, 2
Allows user to compensate for
electrical noise artifact.
• 15 Hz
• 30 Hz (Default)
•Off
Notch Filter
1, 2
Allows user to compensate for power
line noise artifact.
•On (Default)
•Off
1
Caution: Only qualified personnel should access Filter functions.
2
Selection is grayed out if EEG pod is software version VE0.
Message Possible Cause Suggested Action
EEG Check
Electrodes
An EEG channel has
degraded, suggesting poor
electrode contact.
Replace the electrodes.
EEG Pod
Initializing
The EEG pod is warming up. Wait until the pod has warmed up before
attempting to measure.
EEG Pod
Disconnected
The EEG pod is not connected
to the monitor.
Check the cable and connection. Replace the
cable, if necessary.
EEG Pod
Software Failure
An EEG pod software problem
has been detected.
Call your hospital’s technical personnel or
DrägerService.
EEG Pod
Hardware Failure
Loss of communication or
hardware problem detected.
• Check that the EEG pod software is
compatible with the monitor software.
• Check the EEG pod connection.
• Call your hospital’s technical personnel or
DrägerService.
Menu Item Description Available Settings
