7-12 DELTA/DELTA XL/KAPPA VF8
7 R
ECORDINGS
Quick Reference: Reports Setup
Menu Item Description Available settings
ECG Report Prints Rest-ECG report
NOTES:
• A diagnostic ECG Report is available when the
Aries option is installed and the monitor is
connected to the Infinity CentralStation.
• If you are not connected to the Infinity
CentralStation, you can print an ECG waveform
report. See 8, ECG and Heart Rate, for more
information.
Click on the printer
icon to request a
report.
Timed Waveforms Prints a timed recording report (see page 7-6).
Continuous
Waveforms
Prints a continuous recording report
(see page 7-6).
• Click on the printer
icon to request
report.
• Click on the printer
icon again to stop
printing the report.
Waveform Delay Determines the amount of pre-event data included
in the timed recording.
6, 10, 15 s
Waveform Duration Determines the length of timed report. 10, 20 s
Trend Graph Prints a graphical trend report
See chapter 6, Trends, for more information.
Click on printer icon
to request report.
Trend Table Prints tabular trend report
See chapter 6, Trends, for more information.
Trend Duration Determines length of graphical trend report
This item corresponds to the Hours setting at
bottom of Trend Graphs display. See chapter 6,
Trends, for more information.
1, 2, 4, 8, 12, 24 hr
Table Interval Determines time interval for tabular trend report
This item corresponds to the Interval setting at the
bottom of the trend table. See chapter 6, Trends,
for more information.
1, 5, 15, 30, 60 min
