B-18 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
Displays
Display Unit (Kappa only)
See user manuals for the video monitor you are using. Dräger Medical recommends TFT Medical
Grade 15”/17”/19” display. The requirements for the Kappa flat panel are as follows.
Electrical Specifications
Power source:
DC powered, directly from Dräger IDS
Power consumption:
<4 Watts
Isolation:
Not Isolated
Mode of operation:
Continuous
Environmental Requirements
Temperature range:
Operating:10 to +40 °C (50 to 104 °F)
Storage: –20 to +50 °C (–4 to +122 °F)
Relative humidity:
Operating:20 to 90 %, non-condensing
Storage: 10 to 95 % (with packaging)
Atmospheric pressure:
Operating:525 to 795 mmHg (70 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
VGA Display
Output resolution:
High resolution mode: 1024 x 768
Medium resolution mode: 800 x 600
Low resolution mode: 640 x 480
Horizontal frequency:
High resolution mode: 35.5 kHz
Medium resolution mode: 37.9 kHz
Low resolution mode: 31.5 kHz
Vertical frequency:
High resolution mode: 87 Hz (interlaced)
Medium resolution mode: 60 Hz (non-interlaced)
Low resolution mode: 60 Hz (non-interlaced)
Video signal level:
1Vpp
Sync. signal level:
High resolution mode: TTL (positive)
Medium resolution mode: TTL (negative)
Low resolution mode: TTL (negative)
Isolation:
Galvanically isolated from IDS in accordance with IEC 60601-1-1
