MINI-TRENDS
VF8 DELTA/DELTA XL/KAPPA 6-7
The Interval key at the bottom left of the trend table display functions similarly to the
Hours feature in trend graphs (see page 6-4). Settings are
1, 5, 15, 30, or 60 min.
Mini-Trends
You can display up to one hour of trend data for as many as eight parameters while
continuing to monitor main screen waveforms and parameter boxes. Mini-trend
graphs follow the color coding and display order of the parameters they represent and
are updated with new trend data every 60 seconds.
To display Mini-Trends
1. Press the Fast Access fixed key.
2. Click on
Split Screen.
3. Click on
10 Min Trends, 60 Min Trends, Ventilation, or Off.
4. Press the main screen fixed key to exit the menu.
NOTE: The monitor always marks an NBP measurement and a C.O. average with a
time-stamp in the trend table.
