RECORDER S ETUP
VF8 DELTA/DELTA XL/KAPPA 7-9
Primary and Secondary Recorders
You can designate a primary and a secondary recorder or a backup recorder on the
Infinity network. The monitor prints to the designated recorder on the network or to
the local or bedside recorder according to the following criteria:
 The primary recorder prints the recording if no local R50 recorder is
connected to the monitor. The secondary recorder prints the recording if the
primary recorder is not available.
 The local recorder, if connected, prints the requested recording. If a local
recorder is connected but is not available, the secondary recorder executes the
print request.
Alternate Speed Determines the recording speed when
you press the Alternate Speed
(mm/s) key on R50 series recorder.
• 1, 6.25, 12.5, 25, 50 mm/s
Waveform
Selection
Determines whether waveforms to be
printed are selected automatically or
manually.
• Auto - The topmost displayed
waveforms are automatically
selected for recordings.
• Manual - The waveforms that
you have selected are printed
(see Waveform 1 and
Waveform 2 settings).
Waveform 1 Assigns the top waveform for R50
recordings, provided Waveform
Selection is set to Manual
• ECG1, ECG2, RESP, ART,
PA, RV, LV, RA, LA, CVP,
ICP, ICP2, ICP3, ICP4, GP1,
GP2, SpO2, etCO2, etCO2*,
O2, Agent, Paw, Flow, Vol,
EEG1, EEG2, EEG3, EEG4,
BIS
Waveform 2 Assigns the waveform for channel 2 on
R50 recordings, provided Waveform
Selection is set to Manual
Recording mode Displays current recorder
This setting is read-only and cannot be
modified.
Not applicable
Alarm Waveform Gives priority to an alarmed
parameter, which (if Alarm Waveform
is enabled) appears in the second
recording channel regardless of
previous waveform assignments
NOTE: If the alarmed parameter does
not have a waveform (for example,
NBP, TEMP), the recorder prints the
assigned waveform to the second
recording channel.
• ON – Places the waveform
associated with the alarming
condition in a lower recording
channel
Waveforms are printed
according to how you have
configured the Waveform
Selection setting (Auto or
Manual).
•OFF
Menu Selection Description Available Settings
