Quick Reference Table: Paw and Vent Setup
Click on the following menu items to execute setup functions.
Function Description Settings
PAW Setup Menu
Respiratory
Mechanics
Displays a list of continuously updated
ventilator parameters.
See page 21-16 for complete list of
associated parameters.
PV Loop Displays the pressure/volume loop. Not applicable
Paw Scale Sets or changes the size of the
currently displayed pressure (Paw)
waveform.
10, 15, 20, 25, 30, 40, 50, 60, 80, 100,
and 120 cmH20 (upper values)
The monitor automatically sets the
lower waveform value to zero.
Purge Sensor Purges the sensor tubing of water
condensation and patient secretions
(see page 21-8).
NOTES: Pressure and flow
parameters are frozen and no
waveforms are drawn during purging.
Not applicable
PIP Alarm Opens the Alarm Limits table
beginning at the PIP setting.
Not applicable
Mech/Spon
Threshold
Sets the pressure level used to
distinguish spontaneous breathing
from mechanical breathing.
0 - 50 cmH2O
NOTE: The Mech/Spon threshold item may require adjustment based on the patient’s PIP value for
pressure support ventilator modes. If adjustment is not made, all breaths will be considered
mechanical. The appropriate level for the threshold depends on the ventilator.
Gas
Compensation
Informs the monitor of ventilation gas
being used. See page 19-12 for more
information on gas compensation.
Air, N2O/O2, >60 %, Heliox
NOTE: N
2
O/O
2
available in OR mode
only.
Agent
Concentration
(available in OR
mode only)
Informs the monitor of anesthetic
agents in the ventilation gas being
used.
0 - 20 %
• Parameter 1
• Parameter 2
• Parameter 3
Selects up to 3 parameters for display
in the airway pressure parameter box.
PIP, PEEP, MAP, Pause, or None
Clear
Reference
Clears the reference loop from main
screen.
Not applicable
Loop Draw
Sets the number of displayed loops. 1, 4
Split Screen Configures the main screen to display
ventilator or trend data as well as
standard waveforms and parameters.
OFF, 60 Min Trends, 10 Min Trends,
Ventilation
To Next Page
