1-28 DELTA/DELTA XL/KAPPA VF8
1 I
NTRODUCTION
Navigating the Event Recall Screen
To scroll forward and back through 20 seconds of waveform data, click on arrows at
either side of scroll bar at the bottom of the screen.
To scroll through the list of parameter values at the time of data capture, click on the
arrow keys above the list of parameters at the right of the screen:
To scroll through the waveforms displayed at the time of data capture, click on the
Prev (Previous) and Next control buttons under waveform display.
Help Functions
You can display a short description of currently highlighted functions at the bottom of
all active menus by enabling context-sensitive help.
1. Press the
Menu fixed key to open the Main menu.
2. Click on
Monitor Setup. Another column of options appears.
3. Open the
Display Options menu by clicking on that heading.
4. Select
Help Line Display and click to choose ON.
Additional information about the monitor is available in the Main Help menu.
1. Press the
Menu fixed key.
2. Click on
Help. The Main Help Menu appears.
3. Click on the appropriate selection in the table below.
Menu Item Description
Locked Options Displays active software options currently installed on the monitor.
Fixed Keys Describes functions of fixed keys.
