1-12 DELTA/DELTA XL/KAPPA VF8
1 I
NTRODUCTION
Device Markings
The following table describes symbols that appear on the monitor and its accessories
that were not described on pages 1-5 through 1-10:
Monitor on/off Remote keypad in
Battery-operated
equipment
RS 232
Attention! Consult the
accompanying document
Analog out
Defibrillator-proof equipment,
Type CF
Analog out
Direct current Analog out
Danger: Risk of explosion if
used in presence of flammable
anesthetics
Push battery all the way into
compartment.
Isolated patient connection,
Type CF
Close battery compartment
door.
Complies with the European
Medical Device Directive 93/
42/EEC
This end up
Type BF, defibrillator
protected
Artery symbol and arrow
should be placed over
brachial or femoral artery.
Gas in Contains no latex material
Gas out Manufacturer’s lot number
Observe WEEE (Waste
Electrical and Electronic
Equipment) disposal
requirements (see page 2).
Certain cuff codes are
ethylene oxide sterile.
Manufacturing date REF Manufacturer’s reorder code
Alarm out Does not provide isolation
between connected devices
Monitor is receiving AC power Potential equalization
terminal
