104 Chapter2
Adjustment Procedures
12. 10 MHz Reference Adjustment-TCXO (Option 103)
Equipment
Microwave frequency counter ....................... HP 5343A Option 001
Frequency standard ................. HP 5061B Cesium Beam Standard
(or any 10 MHz frequency standard with accuracy <±1 X 10
−10
)
Cables
BNC, 122 cm (2 required) ............................................ HP 10503A
Procedure
NOTE Allow the HP 8560E/EC spectrum analyzer to warm up for at least 30
minutes before performing this adjustment.
1. Connect the equipment as shown in Figure 2-17 on page 103. Prop
up the A14 Frequency Control Assembly.
2. Set the HP 5343A controls as follows:
SAMPLE RATE ..................................................................... Midrange
50 Ω — 1 MΩ SWITCH ......................................................... 50 Ω
10 Hz — 500 MHz/500 MHz — 26.5 GHz SWITCH ............ 10 Hz — 500 MHz
3. Press AUX CTRL, REAR PANEL, and ensure that the 10 MHz reference
is set to
10 MHz INT.
NOTE When the 10 MHz reference is set to 10 MHz EXT, the TCXO is not
operating and warmed up. If the reference is set to
10 MHz
EXT, set the reference to 10 MHz INT and allow 30 minutes for the TCXO
to warm up.
4. Remove dust cap from A15U302, TCXO. The dust cap is toward the
rear of the spectrum analyzer.
5. Adjust 10 MHz ADJ on A15U302 for a frequency counter reading of
300.000000 MHz ±30 Hz.
6. Replace the dustcap on A15U302.
