122 Chapter2
Adjustment Procedures
18. Tracking Oscillator Adjustment (Option 002)
18. Tracking Oscillator Adjustment
(Option 002)
NOTE This is not a routine adjustment. This adjustment should only be
performed if there is insufficient tracking adjustment range.
Assembly Adjusted
A10 tracking generator assembly
Related Performance Test
Tracking Adjustment Range
Description
The centering of the tracking oscillator range is adjusted in the factory
to ensure that the tracking adjustment functions properly. Over a
period of 5 years, however, the center frequency of the tracking
oscillator range may drift outside of acceptable limits. This adjustment
should only be performed if there is insufficient tracking adjustment
range.
This adjustment recenters the tracking oscillator range. The A10
tracking generator is partially removed from the spectrum analyzer to
perform this adjustment. A synthesized sweeper is used as the first
local oscillator signal. A frequency counter is used to measure the
output frequency.
Equipment
Synthesized sweeper...... .............................................HP8340A/B
Microwave frequency counter .......................................HP5343A
50 Ω termination ...........................................................1810-0118
Alignment tool, non-metallic ........................................8710-0033
Cables
SMA, 91 cm (36 in) ........................................................5061-5458
BNC, 122 cm (48 in) (3 required) ............. ...................HP10503A
Adapters
APC 3.5 (f) to APC 3.5 (f) ............................................ 5061-5311 .
SMA (m) to BNC (f) .......................................................1250-1200
BNC tee ..........................................................................1250-0781
