HP 8560E Service Manual

268 Chapter5
Major Assembly and Cable Locations
Introduction
Introduction
This chapter identifies instrument cables and assemblies, and contains
the following figures:
Figure 5-1. Hinged Assemblies........................................... page 270
Figure 5-2. Top View (A2 and A3 Unfolded) EC-series..... page 271
Figure 5-3. Top View (A2, A3, A4, A5 Unfolded) EC-seriespage 272
Figure 5-4. Top View (A2 Unfolded) E-series ................... page 273
Figure 5-5. Top View (A2 and A3 Unfolded) E-series........ page 274
Figure 5-6. Top View (A2, A3, A4,A5 Unfolded) E-series.. page 275
Figure 5-7 Bottom View (A15 Unfolded)............................ page 276
Figure 5-8. Bottom View (A15 and A14 Unfolded)............ page 277
Figure 5-9. Front End......................................................... page 278
Figure 5-10. Rear View - EC-series.................................. page 279
Figure 5-11. Rear View - E-series...................................... page 279
NOTE Diagrams that illustrate features common to E-series and EC-series
instruments are shown with E-series instruments. Where there are
differences between E-series and EC-series features, separate diagrams
are provided for E-series and for EC-series instruments.
Use the list below to determine the figure(s) illustrating the desired
assembly or cable.
Assemblies ............................................................................. Figure
A1 Front Frame ............................................................................... 5-8
A1A1 Keyboard ............................................................................... 5-8
A2 Controller ............................................................................ 5-3,5-4
A3 Interface .............................................................................. 5-1,5-4
A4 Log Amplifier/Cal Oscillator .............................................. 5-1,5-5
A5 IF Filter ............................................................................... 5-1,5-6
A6 Power Supply ............................................................................. 5-6
A6A1 High Voltage Module ............................................................ 5-6
A7 LO Distribution Amplifier ......................................................... 5-7
A8 Low Band Mixer ........................................................................ 5-7
A9 RF Attenuator ............................................................................ 5-7
A10 Tracking Generator (Option 002) ........................................... 5-7
A11 YTO .......................................................................................... 5-7
A12 ............................................................................... (Not Assigned)
A13 Second Converter ..................................................................... 5-7
A14 Frequency Control ............................................................ 5-1,5-8
A15 RF ............................................................................... 5-1, 5-7, 5-8
A16 Fast ADC (Option 007) ..................................................... 5-4,5-6
A17 LCD Driver ....................................................................................
A17 CRT Driver ............................................................................... 5-6
A18 LCD Assembly ...............................................................................
A18 CRT Assembly ......................................................................... 5-6
