HP 8560E Service Manual

Chapter 4 247
Replaceable Parts
Firmware-Dependent Part Numbers
19 0535-0082 2 NVTM W LKWR M4 28480 0535-0082
20 2190-0016 1 WASHER-LK INTL T 3/8 IN .377-IN-ID 28480 2190-0016
21 2950-0043 1 NUT-HEX-DBL-CHAM 3/8-32-THD .094-IN-THK 00000 DESCRIBE
22 1250-2191 1 ADAPTER N(f) SMA (f) (Standard) 28480 1250-2191
22 1250-2191 2 ADAPTER N(f) SMA (f) (Option 002) 28480 1250-2191
23 0515-0430 2 SCREW-MACH M3 X 0.5 8MM-LG PAN-HD TX 28480 0515-0430
24 5041-8985 1 RUBBER KEYPAD (INCLUDES KEYCAPS) 28480 5041-8985
25 1990-1131 1 LED-LAMP LUM-INT=560UCD IF=20MA-MAX 2M627 LD-101MG
26 5062-0728 1 LINE SWITCH CABLE ASSEMBLY 28480 5062-0728
27 0900-0010 1 O-RING .101-IN-ID .07-IN-XSECT-DIA NTRL 51633 AS568-005
28 0515-0664 1 SCREW-MACHINE ASSEMBLYM3 X0.5 12MM-LG 28480 0515-0664
29 5021-5482 1 SUPPORT CENTER 28480 5021-5482
30 0515-1143 2 SCREW-MACH M4 X 0.7 16MM-LG PAN-HD TX 28480 0515-1143
31 0515-1934 9 SCREW-MACH M2.5 X 0.45 6MM-LG PAN-HD TX 28480 0515-1934
(P/O A1W1)
32 2100-4232 1 R-VC 20K 20% LOG 28480 2100-4232
33 3050-0014 2 WASHER-FL .250ID12 28480 3050-0014
34 2190-0067 1 WASHER-LK INTL .256-IN-ID 28480 2190-0067
35 2950-0072 1 NUT-HEX 1/4-32 THD 28480 2950-0072
36 0370-3079 1 KNOB RND .125 JG 28480 0370-3079
Table 4-12 Parts List, Rear Frame − 8560EC (see Figure 4-10)
Item HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
1 0515-1946 2 SCREW-MACH M3 6MM-LG FLH-HD TORX 28480 0515-1946
2 5062-7755 1 BATTERY HOLDER (INCLUDES WIRES) 28480 5062-7755
3 0515-2216 4 SCREW-MACH M4 40MM-LG PAN-HD TORX 28480 0515-2216
4 3160-0309 1 FAN GRILL 28480 3160-0309
5 0380-0012 4 SPACER-RND .875-IN-ID 28480 0380-0012
6 NOT ASSIGNED
7 6960-0149 1 PLUG-HOLE TR-HD FOR 0.5-D-HOLE STL 05093 6960-0149
8 6960-0023 1 PLUG-HOLE DOME-HD FOR 0.312-D-HOLE STL 04213 D-2730-LC2
9 1250-1753 1 ADAPTOR-COAX STR F-SMA OPT 001 28480 1250-1753
(INCLUDES WASHER AND NUT)
10 0515-1946 4 SCREW-MACH M3 6MM-LG FLH-HD TORX 28480 0515-1946
11 0515-0684 1 SCREW-MACH M3 6MM-LG PAN-HD TORX 28480 0515-0684
12 2950-0035 5 NUT HEX 15/32THD 28480 2950-0035
13 5062-4838 1 CONNECTOR-TEL 2-CKT .141-SHK-DIA 28480 5062-4838
(INCLUDES NUT AND JACK) PART OF W5
14 5002-4049 1 REAR PANEL-DRESS 28480 5002-4049
15 0515-2145 4 SCREW-MACH M3 6MMLG PAN-HD TORX 28480 0515-2145
16 8160-0520 1 RFI ROUND STRIP STL SPIRA .150 28480 8160-0520
Table 4-11 Parts List, Front Frame − 8560E (see Figure 4-5)
Item HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
