HP 8560E Service Manual

242 Chapter4
Replaceable Parts
Firmware-Dependent Part Numbers
Table 4-6 Parts List, Cover Assembly (See Figure 4-2) − 8560E and 8560EC
Item HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
1 5041-8911 1 BAIL HANDLE 28480 5041-8911
2 5041-8912 2 TRIM CAP 28480 5041-8912
3 0515-1114 4 SCREW MACH M4 X 10MM-LG PAN-HD 28480 0515-1114
4 1460-2164 2 SPRING-CPRSN .845 IN-OD 1.25-1N-OA-LG 28480 1460-2164
5 5021-6343 2 RING GEAR 28480 5021-6343
6 5021-6344 2 SOCKET GEAR 28480 5021-6344
7 5021-8667 2 HANDLE PLATE 28480 5021-8667
8 5001-8728 2 BACKUP PLATE 28480 5001-8728
9 0515-1367 6 SCREW MACH M4 X 8MM-LG 90DEG-FLH-HD 28480 0515-1367
10 0515-1133 2 SCREW-MACH M5 X 16MM-LG 28480 0515-1133
11 5001-8800 1 COVER 28480 5001-8800
12 5041-7238 1 MOISTURE DEFLECTOR-LF 28480 5041-7238
13 5041-3989 1 MOISTURE DEFLECTOR-RT 28480 5041-3989
14 5041-8913 2 SIDE TRIM 28480 5041-8913
15 0515-1114 2 SCREW-MACH M4 X 10MM-LG PAN-HD 28480 0515-1114
16 5041-8907 2 REAR FOOT 28480 5041-8907
17 0900-0024 4 O-RING .145-1N-XSECT-DIA SIL 51633 A5568-007
18 2190-0587 4 WASHER-LK HLCL 5.0 MM 5.1-MM-ID 28480 2190-0587
19 0515-1218 4 SCREW-SKT-HD-CAP M5 X 40MM-LG 28480 0515-1218
20 08562-80028 1 INSULATOR 292 X 355 MM .51 THK 28480 08562-80028
Table 4-7 Parts List, Main Chassis − 8560EC (see Figure 4-8)
Item HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
1 0515-2145 4 SCREW-MACH M3 X 8MM-LG PAN-HD TORX 28480 0515-2145
4 0380-2052 2 SPACER 0.937LG 0.166ID 28480 0380-2052
5 5002-1010 1 COVER, A6 POWER SUPPLY (Includes label) 28480 5002-1010
6 0515-2309 3 SCREW-MACH M3 X 0.5 45MM-LG TORX 28480 0515-2309
7 5041-7246 1 BOARD MOUNT 28480 5041-7246
8 0515-0372 2 SCREW-MACH M3 X 8MM-LG PAN-HD TORX 28480 0515-0372
14 5002-1008 1 MAIN DECK 28480 5002-1008
15 5002-1002 1 FRONT END DECK 28480 5002-1002
16 0515-1101 4 SCREW-MACH M4 X 8MM-LG FLH-HD TORX 28480 0515-1101
17 0515-1227 2 SCREW MACH M3 X 6MM-LG FLH-HD TORX 28480 0515-1227
18 5021-7464 2 SIDE FRAME 28480 5021-7464
19 0515-1101 12 SCREW-MACH M4 X 8MM-LG FLH-HD TORX 28480 0515-1101
20 0515-1227 12 SCREW MACH M3 X 6MM-LG FLH-HD TORX 28480 0515-1227
21 0515-1227 8 SCREW MACH M3 X 6MM-LG FLH-HD TORX 28480 0515-1227
22 0515-1227 5 SCREW MACH M3 X 6MM-LG FLH-HD TORX 28480 0515-1227
23 5021-5484 5 MOUNTING POST 28480 5021-5484
24 5062-0750 2 HINGE, 2 BOARD 28480 5062-0750
25 5062-0751 2 HINGE, 4 BOARD 28480 5062-0751
26 5041-7250 1 CABLE CLAMP 28480 5041-7250
