HP 8560E Service Manual

Chapter 4 233
Replaceable Parts
Firmware-Dependent Part Numbers
Table 4-4 Replaceable Parts
Reference
Designator
HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
ACCESSORIES SUPPLIED
1810-0118 1 TERMINATION-COAXIAL SMA; 0.5W; 50Ω 16179 2003-6113-02
1250-0780 1 ADAPTER-COAX F-BNC M-N 24931 29JP104-2
HP 10502A 1 50Ω COAX CABLE WITH BNC MALE 28480 HP 10502A
8710-1755 3 WRENCH-HEX KEY 55719 AWML4
OPTION 908
5062-0800 1 RACK KIT WITH FLANGES
(Includes Parts Listed Below)
5001-8739 2 PANEL-DRESS 28480 5001-8739
5001-8740 2 PANEL-SUB 28480 5001-8740
5001-8742 2 SUPPORT-REAR 28480 5001-8742
5021-5807 2 FRAME-FRONT 28480 5021-5807
5021-5808 2 FRAME-REAR 28480 5021-5808
5021-5836 5 CORNER-STRUT 28480 5021-5836
0510-1148 10 RETAINER-PUSH-ON KB-TO-SHFT EXT 11591 669
0515-0886 16 SCREW-MACH M3 × 0.5 6MM-LG PAN-HD 28480 0515-0886
0515-0887 8 SCREW-MACH M3.5 × 0.6 6MM-LG PAN-HD 28480 0515-0887
0515-0889 12 SCREW-MACH M3.5 × 0.6 6MM-LG 28480 0515-0889
0515-1241 8 SCREW-MACH M5 × 0.8 12 MM-LG PAN-HD 28480 0515-1241
0515-1331 22 SCREW-METRIC SPECIALTY M4 × 0.7 THD; 7MM 28480 0515-1331
5061-9679 2 MOUNT FLANGE 28480 5061-9679
0515-1114 6 SCREW-MACH M4 × 0.7 10MM-LG PAN-HD 28480 0515-1114
8710-1755 WRENCH-HEX KEY 55719 AWML4
5958-6573 2 ASSEMBLY INSTRUCTIONS 28480 5958-6573
OPTION 909
5062-1900 1 RACK KIT WITH FLANGES AND HANDLES
(Includes Parts Listed Below)
5001-8739 PANEL-DRESS 28480 5001-8739
5001-8740 PANEL-SUB 28480 5001-8740
5001-8742 SUPPORT-REAR 28480 5001-8742
5021-5807 FRAME-FRONT 28480 5021-5807
5021-5808 FRAME-REAR 28480 5021-5808
5021-5836 CORNER-STRUT 28480 5021-5836
0510-1148 RETAINER- PUSH-ON KB-TO-SHFT EXT 11591 669
0515-0886 SCREW-MACH M3 × 0.5 6MM-LG PAN-HD 28480 0515-0886
0515-0887 SCREW-MACH M3.5 × 0.6 6MM-LG PAN-HD 28480 0515-0887
0515-0889 SCREW-MACH M3.5 × 0.6 6MM-LG 28480 0515-0889
0515-1241 SCREW-MACH M5 × 0.8 12MM-LG PAN-HD 28480 0515-1241
0515-1331 SCREW-METRIC SPECIALTY M4 × 0.7 THD; 7MM 28480 0515-1331
5061-9501 2 FRONT HANDLE ASS'Y 28480 5061-9501
5061-9685 2 MOUNT FLANGE 28480 5061-9685
