Section
6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-16 2450-901-01 Rev. B/September 2013
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]
This command specifies the lower limit for limit tests.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
-1.000000E+00
Usage
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] <n>
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]?
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]? DEFault
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]? MINimum
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA]? MAXimum
<function>
The function to which this setting applies:
• Current: CURRent[:DC]
• Resistance: RESistance
•
Voltage: VOLTage[:DC]
<Y>
The limit test that the lower limit applies to, 1 or 2
<n>
The value of the lower limit (
−
9.99999e+11 to +9.99999e+11)
Details
This command sets the lower limits for the limit tests for the selected measurement function. When limit Y testing
is enabled, this causes a fail indication to occur when the measurement value is less than this value.
If you send this command without the <function> parameter, it will set the limit for all functions.
Example
CALC2:VOLT:LIM1:LOW 0.25
CALC2:VOLT:LIM1:UPP 2.5
CALC2:VOLT:LIMIT1:STAT ON
CALC2:VOLT:LIMIT1:FAIL?
Set lower limit 1 for voltage to 0.25 volts.
Set upper limit 1 for voltage to 2.5 volts.
Enable limit 1 testing for voltage.
Check the test results.
Also see
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 6-18)
