6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-74 2450-901-01 Rev. B/September 2013
:SOURce[1]:<function>:PROTection[:LEVel]:TRIPped?
This command indicates if the overvoltage source protection feature is active.
Type Affected by Where saved Default value
Query only Not applicable Not applicable Not applicable
Usage
:SOURce[1]:VOLTage:PROTection[:LEVel]:TRIPped?
Details
When overvoltage protection is active, the instrument restricts the maximum voltage level that the instrument can
source.
If the voltage source does not exceed the set limits, the return is 0. If the voltage source exceeds the set limits,
the return is 1.
Example
SOUR:VOLT:PROT:TRIP?
If overvoltage protection is active, the output is:
1
Also see
Overvoltage protection (on page 2-98)
:SOURce[1]:<function>:PROTection[:LEVel] (on page 6-73)
:SOURce[1]:<function>:RANGe
This command selects the range for the source for the selected source function.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Source configuration list
Save settings
Source configuration list
Current: 1e-04
Voltage: 20 mV
Usage
:SOURce[1]:<function>:RANGe <n>
:SOURce[1]:<function>:RANGe?
:SOURce[1]:<function>:RANGe? DEFault
:SOURce[1]:<function>:RANGe? MINimum
:SOURce[1]:<function>:RANGe? MAXimum
<function>
The source function to which this setting applies:
• Current: CURRent
• Voltage: VOLTage
<n>
Set to the maximum expected voltage or current to be sourced; the
ranges are:
• Current: −1 A to 1 A
•
Voltage:
−
200 V to 200 V
